| # | 部品詳細 | 価格 （各） | 図の数量 | カートに追加 |
|---|---|---|---|---|
| - |
AD232C465BA Parkbrake Caliper Assembly Rear LH Painted |
$530.84 | 1 | |
| - |
AD232C464BB Parkbrake Caliper Anodized, Rear RH w/o Pads Anodised |
$672.88 | 1 | |
| - |
AD232C465BB Parkbrake Caliper Anodized, Rear LH w/o Pads Anodised |
$672.88 | 1 | |
| - |
4G43224259BA Spring, Anti-rattle (1 per caliper) ARRIVING SOON |
$68.14 | 2 | |
| - |
4G436510059 Clip, Firtree, 5x6.5x2 - |
- | 1 | Enquire |
| 1 |
4G438492AC Handbrake Lever Assembly LHD - |
- | 1 | Enquire |
| 2 |
4G432A686AB Bracket Assembly, Brake Lever - |
$866.86 | 1 | |
| 3 |
703121 SCREW, M8x2,0 HEX FLG - |
$0.48 | 6 | |
| 4 |
8D332853AB HANDBRAKE CABLE ASSEMBLY - |
$357.22 | 1 | |
| 6 |
6G332K605AA Pivot Pin, H/brake Cable to Lever - |
$1.69 | 1 | |
| 7 |
6G33100063AA Push fix M6 - |
- | 1 | Enquire |
| 8 |
AD232C464BA Parkbrake Caliper Assembly Rear RH Painted |
$591.53 | 1 | |
| 9 |
4G432C564CA Bolt, Flange Head M10x87 - |
$3.44 | 4 | |
| 11 |
694891 Pクリップ、10MM - |
$4.44 | 4 | |
| 12 |
703203 Screw, Flange Head M6x20 - |
$0.34 | 3 | |
| 13 |
703163 Nut, M06, hex flange head - |
$0.23 | 3 | |
| 14 |
8D33-229047-BA PIGTAIL CLIP - |
- | 2 | Enquire |
| 15 |
8D332B296BA ピン、パッド保持 (1 per caliper) |
$59.35 | 2 |
