| # | 部品詳細 | 価格 （各） | 図の数量 | カートに追加 |
|---|---|---|---|---|
| - |
9D336696YBA SPEAKER, DOOR, LH - |
$462.84 | 1 | |
| - |
9D3346685AA スピーカー、リア、左側 - |
$317.69 | 1 | |
| 1 |
9D3318C956AB サブウーファー＆エンクロージャー - |
$885.21 | 1 | |
| 2 |
6G33FA0115AB Screw and Washer M6x19 Pan Int - |
- | 2 | Enquire |
| 3 |
703164 Nut M6 Hex flg plastic - |
$0.79 | 2 | |
| 4 |
9D336696XBA SPEAKER, DOOR, RH - |
$462.84 | 1 | |
| 5 |
700607 Screw M6x20 Hex Flng Hd - |
$0.31 | 4 | |
| 6 |
9D3346684AA スピーカー、リア、右側 - |
$317.69 | 1 | |
| 7 |
703735 SCREW, M5x12, PAN HEAD - |
$0.56 | 4 | |
| 8 |
9D3318D801AA Acoustic lens tweeter assy - |
- | 2 | Enquire |
| 9 |
9D3346662AA WASHER, 14mm 43ID 14OD0.8 THK - |
$0.11 | 3 per assy | |
| 10 |
701441 Screw, M4.2 x 13 - |
- | 3 per assy | Enquire |
| 11 |
9D3370451AA Speaker Box Assembly, Centre - |
- | 1 | Enquire |
| 12 |
703736 Screw, ST 4.2 x 16 large washer head - |
$0.13 | 4 | |
| 13 |
9D336696XAB Speaker, footwell, RH - |
- | 1 | Enquire |
| 14 |
9D336696YAB Speaker, footwell, LH - |
- | 1 | Enquire |
| 15 |
tbc Rivnut, M8, low profile - |
- | 2 per assy | Enquire |
| 16 |
9D3319080AA Bracket Assy, Speaker - |
$18.20 | 2 | |
| 17 |
9D332B100AA Bracket, footwell speaker, RH - |
- | 1 | Enquire |
